Product synopsis
PTFE series is constructed of imported natural hydrophobic Polytetrafluoroethylene membrane media and non-woven support materials. Adaptors are thermally welded with media without using any glue on it, so there is no possibilities to cause pollution.
Features
● Excellent chemical compatibility. Suitable for filtering organic solvents, acid bases.
● Pleated design increased the filtration area.
● low pressure drop, long service life
● Full range of removal ratings
Specifications
● Removal ratings: 0.1μm, 0.2μm, 0.45μm, 1μm, 3μm, 5μm, 10μm, 20μm, 30μm, 50μm
● Length: 10", 20", 30", 40"
● Outside diameter: 69mm
● Maximum operating temperature: 80℃ @1 bar,support adaptors are recommended for temperature exceeds 50℃
● Maximum operating differential pressure: 4.0bar ,normal temperature
● Maximum operating differential pressure (reverse direction): 2.0bar normal temperature
● Sterilization temperature time: 5times, 20 Minute cycles at 120℃
Applications
● Pharmaceutics
● Food and beverage
● Oil industry
● Semiconductor
● Chemical industry
Order information :
|
Filtering precision |
length |
Plateform |
Seal material |
|
0.1um |
9.75'' |
Double open |
Silicone rubber,
|
|
0.22um |
10'' |
Inside o-rings/ flat blank cap
|
ethylene propylene rubber, |
|
0.45um |
20'' |
222/height222/Triangle pointed/conneres pointed
|
butadiene acrylonitrile rubber, |
|
|
30'' |
222/height 222/tail wing |
fluorine rubber |
|
|
40'' |
222/height222/flat blank cap |
|
|
|
|
226/Triangle pointed/conneres pointed |
|
|
|
|
226tail wing |
|
|
|
|
226flat blank cap |
|
