High Flowment Water Filter(152 mm)
Products introduction
The filter use high-performance filter material and integrate of high efficiency and compact features from pleated filter and convenience
and simple operation features from filter bag.The pleated filter material filter design increase effective filtering area. Due to large flow,
service life is long and change is reduced then the costs of investment and labor is reduced in many applications.
Application field :
l RO Security filtering,sea water desalination pretreatment
l Power plant of condensed water filtration
l Biological pharmaceutical industry raw materials, solvents, water filtration
l Bottled water, sugar solution, cooking oil, fruit juice, soft drinks, milk filtration
l Paint,oil chemical industry
l Microelectronics, film, fiber and resin
Products Properties:
l Gradient hole stem structure
l Large folding structure
l Filter diameter 6 ''(152 mm), suitable to the large flow and high capacity
l High mechanical strength, even in harsh process conditions ,it will not break
l Flow direction from inside to outside ensures that all impurities trapped in the internal filter
l Can be installed directly in the existing shell, need no change and transformation
Technical Specifications:
Filter size
l Outer diameter : 6''(152mm)
l Length : 10'',20'',30'',40''
Parts material :
l Filter material : pleated deep polypropylene(pp)
l Support: polypropylene
l End cover: polypropylene
l Conversion flange: polypropylene
l Seal ring material: ethylene propylene rubber, butadiene acrylonitrile rubber
Filter cartridge :
l Filteringprecision:0.5um,1um,3um,5um,10um,20um,40um,70um,100um,120um
l The highest operating temperature : 60℃
l Maximum pressure drop : 3.4 Bar 60℃
l Filter replacement company recommended pressure drop: 2.4Bar 20℃
Order information :
|
Precision |
length |
Conversion type
|
Seal ring material |
|
0.5um |
10'' |
Used for shell entering the side into the end |
Ethylene propylene rubber |
|
1um |
20'' |
Used for shell entering at top and leaving at bottom |
Butadiene acrylonitrile rubber
|
|
3um |
30'' |
|
|
|
5um |
40'' |
|
|
|
10um |
|
|
|
|
20um |
|
|
|
|
40um |
|
|
|
|
70um |
|
|
|
|
100um |
|
|
|
|
120um |
|
|
|
