Brand Name: LEFILTER
Model Number:
Nominal filtration rating:
Application:
Working temperature: 10-80℃
Replacement or not:Replacement
Parker Filter element provides a filtering scheme which can effectively replace deep and other inner diameter 2-1/2" forms in heavy- flowing situations, such as anti-osmosis pre-filtering and similar efficiency-catering occasions. Each park series filter can process flow of 1300 liter/minute, which significantly reduces the filter quantity and size. The capacity of a park filter is equivalent to 10 filters with diameter 2-1/2", length 40". Positively charged type O sealing ring and a built-in handle make the filter installation fast, safe and convenient.
Filter material: glass fiber, polypropylene(PP),
Support/Diversion layer: polypropylene(PP)
The end cap: reinforced polypropylene with glass fiber
Seal ring material: EPR (Ethylene-Propylene Rubber), silicon rubber, nitrile rubber, fluorine rubber
Filtering accuracy:1μm,4.5μm,6μm,10μm,20μm,40μm,70μm,100μm
Highest operating temperature: 82ºC
Maximum pressure drop: 3.4bar,82ºC
Recommended maximum filtering water flow: 1300LPM
Pretreating of RO cartridge filtration, seawater desalination
Filtration of condensed water in power plants
Filtration of bulk drug, solvent, and water in bio-pharmacy industry
Filtration of bottled water, liquid glucose, edible oil, juice, softdrink and milk
Painting, petrochemical industry
Micro-electronics, film, fiber, resin
