ZU-H, QU-H HIGH PRESSURE LINE FILTER SERIES
ZU-H,QU-H series filters are high pressure type and used in the pressure line of hydraulic system.
Filter element is made of glass fibre or paper.Differential pressure indicator signals when the pressure drop across filter element reaches 0.35MPa
Model Code:
1 2 *3-4 5 x 6 7 8
1:
ZU:Paper inside filter element
QU:Fiberglass inside filter element
WU:Wire mesh inside filter element
2:
I:With by-pass valve
Blank:no by-pass valve
3:
BH:Water-glycol
Blank:hydraulic oil
4:
Pressure class: H:32MPa
E:22MPa
5:
Flow rate (L/min)
6:
Filtration accuracy ( μm)
7:
Blank:thread connection
F: flanged connection
B: plated connection
DL: inverted threaded connection
DF: inverted flanged connection
DFA: inverted flanged connection A
DFB: inverted flanged connection B
BD: inverted plated connection
8:
P:CMS indicator
Blank:no indicator
Technical data:
|
Model |
Dia.
(mm) |
Flow rate
(L/min) |
Filtr.
(μm) |
Press
(MPa) |
Pressure loss(MPa) |
Indicator power |
Weight
(Kg) |
Filter element |
Connection type |
|
Initial |
Max. |
|
ZU/QU-H10x*P |
15 |
10 |
1
3
5
10
20
30 |
32 |
0.08 |
0.35 |
24V/48w
220V/50W |
3.6 |
HX-10x*# |
Thread |
|
ZU/QU-H25x*P |
25 |
5.0 |
HX-25x*# |
|
ZU/QU-H40x*P |
20 |
40 |
0.1 |
8.0 |
HX-40x*# |
|
ZU/QU-H63x*P |
63 |
9.8 |
HX-63x*# |
|
ZU/QU-H100x*P |
25 |
100 |
12.0 |
HX-100x*# |
|
ZU/QU-H160x*P |
32 |
160 |
0.12 |
18.2 |
HX-160x*# |
|
ZU/QU-H250x*P |
40 |
250 |
23.0 |
HX-250x*# |
Flange |
|
ZU/QU-H400x*P |
50 |
400 |
0.15 |
33.8 |
HX-400x*# |
|
ZU/QU-H630x*P |
53 |
630 |
42.0 |
HX-630x*# |
|
ZU/QU-H800x*P |
800 |
52.0 |
HX-800x*# |
Note: * is represents filtration, # is filter media If the filter fluid is water-glycol, usage pressure 32MPa,flower rate 63L/min,
filter media is paper,the filter equipped with indicator and by-pass valve, the model of the fi-lter is ZUI BH H63 *P. That of
the element is HX BH H63 *, if filter media is fibre and the filter equipped with indicator,the model of the filter is QU BH H63 *P,
that of the element is HX BH H63 *Q;if filter media is wire mesh and the filter equipped with indicator, the model of the filter is
WU BH H63 *P,That of the element is HX BH H63 *W;
For more filters details,contact us,please.
