    TF-25x80L-Y Tank mounted suction oil filter

    Read 0 Reviews23 Q&As Write a Review
    1.For hydraulic oil 2.Professional manufacturer 3.Good quality 4.Competitive price

    PARAMETER

    Brand Name:
    Model Number:
    Nominal filtration rating:
    Application:
    Working temperature:
    Replacement or not:Replacement

    TF-25x80L-Y Tank mounted suction oil filter



    1.INTRODUTION

     The TF-series filters can be installed on the top, at the side or in the bottom of the tank.. There is a check valve inside the filter. During maintenance. When filter element is withdrawn for washing, the check valve will chose automatically to stop oil flowing out from the tank.
       A vacuum indicator in the filter gives signals when the pressure drop across the element reaches 0.018Mpa showing that the filter cleaned. If no maintenance is done, as the pressure drop rises to 0.02Mpa, the by-pass valve will open to allow oil flowing into pump.

    2.TECHNICAL DATA

    Model Flow(L/min) Filtr(um) Dia(mm) InitialΔp(Mpa) Indicator Connection  Weight Model of element
    V A
    TF-25X*L-C/Y 25


    80


    100


    180    		 15





    <0.01

    12

    24

    36

    220

    2.5

    2

    1.5

    0.25

    THREAD    		 0.4 TFX-25X*
    TF-40X*L-C/Y 40 20 0.45 TFX-40X*
    TF-63X*L-C/Y 63 25 0.82 TFX-63X*
    TF-100X*L-C/Y 100 32 0.87 TFX-100X*
    TF-160X*L-C/Y 160 40 1.75 TFX-160X*
    TF-250X*F-C/Y 250 50

    FLANGE    		 2.6 TFX-250X*
    TF-400X*F-C/Y 400 65 4.3 TFX-400X*
    TF-630X*F-C/Y 630 90 6.2 TFX-630X*
    TF-800X*F-C/Y 800 90 6.9 TFX-800X*
    TF-1000X*F-C/Y 1000 90 8 TFX-1000X*
    TF-1300X*F-C/Y 1300 90 10.4 TFX-1300X*


    Note:* is filtration accuracy,If the medium is water-glycol,flow rate is 160L/min,filtration accuracy is 80 um,with ZS-I Indicator,the model of this filter IS TF.BH-160X80L-C,The model of element is TFX.BH-160X80.
