Suction Line Filter
1. Suction Line Filter Introduction
The filter is composed by aluminum alloy shell, element, by- pass valve,visible indicator and electrical indicator.Light but very strong, it is installed on the outside line, the size
of tank is not confined by the filter.
2. Suction Line Filter Technical Parameter
Media: Hydraulic oil, water-glycol
Flow rate: 40-1000L/min Precision:80-180μm
Pressure:0.6MPa Connecting:Flange
3.Lectotype illustration
The model of filter is ISV•BH40-160＊80C,element is IX-BH-160＊80 with ZS-I indicator if the flow rate is 160L/min,
the precision is 80μm.
