Fiberglass filter separator elements

Read 0 Reviews23 Q&As Write a Review

Fiberglass filter separator elements CONSTRUCTION Media Polyester or Polypropylene Gaskets/End Cap Integral thermally bonded polyester or polypropylene. Optional buna-n or viton with metal end caps. Core None in standard construction. If re

PARAMETER

Brand Name:
Model Number:
Nominal filtration rating:
Application:
Working temperature:
Replacement or not:Replacement

Product Description

CONSTRUCTION

•Media Polyester or Polypropylene

•Gaskets/End Cap Integral thermally bonded polyester or polypropylene. Optional buna-n or viton with metal end caps.

•Core None in standard construction. If required — louvered, carbon steel.

OPERATIONAL DATA

•Recommended Element Change Out: 12 - 14 PSID / .83 - .97 bar.

•See chart below for collapse strengths

•Maximum Operating Temp: Polyester 240º F / 116º C Polypropylene 180º F / 82º C Note: Temps from 200º - 240ºF require a core for 4.5” & 5.5” O.D. filters.

•Micron Ratings: 0.5, 1, 5, 10 SCW=0.3

•Recommended Torque to Seal Filters: 5-10 ft-lbs NOTE: This Torque should not be exceeded.
