    UTR Top Loaded Pluse Pleated Air Filter Cartridge

    Read 0 Reviews23 Q&As Write a Review
    UTR Top Loaded Pluse Pleated Air Filter Cartridge UTR standard structure Top and bottom of the structure of special polyurethane Perforated glavanized steel stainless steel or stainless steel net 100% polyester filament spinning clay filter

    PARAMETER

    Brand Name:
    Model Number:
    Nominal filtration rating:
    Application:
    Working temperature:
    Replacement or not:Replacement


    UTR Top Loaded Pluse Pleated Air Filter Cartridge

    UTR standard structure
    Top and bottom of the structure of special polyurethane
    Perforated glavanized steel stainless steel or stainless steel net
    100% polyester filament spinning clay filter media filter
    Continuouse operating temperature of 107 ℃
    Tube sheet hole about 5mm thickness
    Rubber ring or silicone ring for food industry
    No metal parts with the dusty gas

    Optional after-treatment:PTFE and anti-static coating surface,waterproof and anti-oil treatment.

    Specification:
    Model Cover material Tube sheet H.D(mm) Top cover
    O.D(mm)    		 Bottom cover
    O.D(mm)    		 Filtration surface/1m Filtration surface/2m
    TRLF/LU 133 Polyurethane 133 142 120 2.0m2 4.0m2
    TRLF/LU 153 Polyurethane 153 160 140 2.1m2 4.3m2
    TRLF/LU 159 Polyurethane 159 169 145 2.3m2 4.6m2
    TRLF/LU 162 Polyurethane 162 169 150 2.3m2 4.6m2
